365nm uv led curing machine

Model:HTCS-II-FS150100-NL

UVLED curing machine, to replace the traditional mercury lamp, low temperature, no ozone, no deep UV, low energy consumption, high efficiency.


Product SurveySpecification ParameterProduct Dimension Drawing

HTCS-II-FS150100-NL is a high-performance UVLED  curing system, the system includes the controller,

UVLED irradiation head and cable. UVLED head with imported high-intensity UV LED integrated UV spectral

wavelength of 365nm, 385nm, 395nm, 405nm, the use of forced air cooling, the effective curing area of 100x150mm,

support for external signal input and trigger, can be equipped with semi-automatic or fully automated production line .
